The Mofidi 2,000 L/min Piston Air Compressor is a practical solution for large workshops and industrial facilities requiring a reliable supply of compressed air.
This model is available in two configurations:
horizontal and skid-mounted,
with different tank capacities to meet various compressed-air requirements.
Mofidi 2,000 L/min Piston Air Compressor
Horizontal Model
The horizontal model is available with
1,000-liter and 1,250-liter tanks,
allowing users to select the appropriate storage capacity according to their compressed-air demand.
Skid-Mounted Model
The skid-mounted model is available with a
1,250-liter tank
and is suitable for industrial applications requiring high air storage capacity.
Technical Specifications
The maximum working pressure of this compressor is
8 bar (116 PSI), making it suitable for a wide range of industrial and workshop applications.
The compressor is equipped with a 15 kW (20 HP) motor
and provides an air intake capacity of 2,000 L/min (70.1 CFM).
The piston speed is 950 RPM, providing suitable operating performance
for demanding and continuous compressed-air applications.
Applications of the Mofidi 2,000 L/min Piston Compressor
Large Workshops and Factories
Suitable for large workshops and factories that require compressed air for
industrial tools such as turning machines, milling machines, air cutters,
punches, and other high-consumption equipment.
Construction and Industrial Projects
Its high air delivery capacity makes it suitable for construction and industrial
projects where pneumatic tools are used over extended operating periods.
Important Points Before Purchasing
Air Consumption
Calculate the combined air consumption of all pneumatic tools and equipment
and consider their operating cycles.
Tank Capacity
Choose between the 1,000-liter and 1,250-liter tank options according
to your required compressed-air storage capacity.
Noise and Vibration
For work environments where noise and vibration are important considerations,
the skid-mounted configuration with suitable vibration isolation may be preferred.
Maintenance and Spare Parts
Consider routine maintenance requirements, availability of spare parts,
warranty coverage, and after-sales support when selecting the compressor.
Warranty and After-Sales Service
Mofidi Air Industry provides a
6-month warranty from the date of purchase.
In addition, all piston compressors are supported by
10 years of after-sales service from the date of purchase.
Need More Information?
If you are considering purchasing the
Mofidi 2,000 L/min Piston Air Compressor,
contact our sales team through the phone numbers listed on the website
for technical consultation and purchasing assistance.
Mofidi 2,000 L/min Piston Air Compressor
2,000 Liters – 20 HP
Mofidi 2,000 L/min Piston Air Compressor – Technical Specifications
| Specification | Value |
|---|---|
| Model | 2000 CMI |
| Compressor type | Piston (reciprocating) |
| Air delivery (intake) | 2,000 L/min (70.1 cfm) |
| Working pressure | 8 bar (116 psi) |
| Motor power | 15 kW (20 HP) |
| Piston speed | 950 RPM |
| Power supply | three-phase 380 V |
| Tank size | 1000 or 1250 liters |
The “2,000 L/min” in the name of this compressor is its air delivery (2,000 liters of air per minute), not the tank size. It is supplied with a 1000 or 1250-liter tank.
What Is the 2,000 L/min piston air compressor Suitable For?
With a 20 HP motor and three-phase 380 V power supply, the Mofidi 2,000 L/min piston air compressor is a good choice for factories and production lines with high air demand and long running hours that have three-phase industrial power. If you need less air, see the 1,500 L/min piston air compressor. For higher demand, see the 3,000 L/min piston air compressor.
Compare Mofidi Piston Air Compressors
| Model | Air delivery | Motor | Pressure | Power supply |
|---|---|---|---|---|
| 100 L/min | 100 L/min | 1 HP | 8 bar | Single-phase |
| 200 L/min | 200 L/min | 1.5 HP | 8 bar | Single-phase |
| 300 L/min | 300 L/min | 2 HP | 8 bar | Single-phase |
| 350 L/min | 350 L/min | 3 HP | 8 bar | Single-phase |
| 450 L/min | 450 L/min | 4 HP | 10 bar | Three-phase |
| 650 L/min | 650 L/min | 5.5 HP | 10 bar | Three-phase |
| 830 L/min | 830 L/min | 7.5 HP | 10 bar | Three-phase |
| 1,000 L/min | 1,000 L/min | 10 HP | 10 bar | Three-phase |
| 1,200 L/min | 1,200 L/min | 10 HP | 10 bar | Three-phase |
| 1,500 L/min | 1,500 L/min | 15 HP | 8 bar | Three-phase |
| 2,000 L/min | 2,000 L/min | 20 HP | 8 bar | Three-phase |
| 3,000 L/min | 3,000 L/min | 25 HP | 8 bar | Three-phase |
For more guidance, read Mofidi Piston Compressor: A Powerful and Cost-Effective Choice and our Guide to Choosing the Right Industrial Compressor.
Mofidi 2,000 L/min Piston Air Compressor – FAQ
What does “2,000 L/min” mean?
It means the compressor takes in 2,000 liters of air per minute (70.1 cfm). The tank size is 1000 or 1250 liters.
What is the working pressure?
8 bar (116 psi).
Does it run on single-phase or three-phase power?
It requires a three-phase 380 V industrial power supply.
What is the motor power?
15 kW (20 HP).
Buy the Mofidi 2,000 L/min Piston Air Compressor
Contact Mofidi Air Industry for help choosing the right model and tank size, and for a quote. See all models in Piston Air Compressors.
